Industrial High Temperature Vacuum Furnace / Lab Sintering Furnace 2400 ° C

Product Description

Industrial High Temperature Vacuum Furnace / Lab Sintering Furnace 2400 ° C

High Temperature Vacuum Furnace Application:

High Temperature Vacuum Furnace is mainly used for sintering of vacuum and atmosphere sintering of silicon carbide, ceramics, cemented carbide, powder metallurgy, tungsten, molybdenum, alumino-nickel-cobalt permanent magnet, Smco5, Sm2co17, aluminum alloy shed, titanium alloy and other alloy materials. According to the needs of the sintering process time, a single set of power supply can be used to configure multiple electric furnaces, and the individual furnaces are respectively energized to heat up and power off and cool down to achieve continuous operation.

High Temperature Vacuum Furnace Main Specifications

Common temperature: 2400 ° C

High temperature zone volume: 200-2000mm × 300-4000mm; or square

Heating method: induction heating

Working gas in the furnace: nitrogen argon

Temperature uniformity: ≤ ± 10 ° C

Temperature control: PID intelligent program control and manual control

Temperature control accuracy: ±1 °C

According to the needs of the sintering process time, multiple electric furnaces can be arranged in a single power supply, and the heating and cooling of the individual furnaces can be respectively performed to achieve continuous operation.

The device has data logging and dumping functions, and the data can be viewed through historical curves and can be transferred to removable storage media.
