Sintering Thermo Scientific Muffle Furnace Industrial Lab Heating Equipments

Minimum Order Quantity :	Negotiable	Price :	Negotiable
Packaging Details :	Carton, pallet, wooden case or according to customer's package requirements	Delivery Time :	30 working days
Payment Terms :	30% deposit + 70% T/T before shipping	Supply Ability :	20 sets per month

Place of Origin:	CHINA	Brand Name:	OEM
Certification:	CE Certification	Model Number:	OEM

Detail Information
Heating Source:	Microwave & Electric	Working Temperature:	0~1550℃
Temperature Measurement Method:	Infrared Thermometer	Temperature Accuracy:	±0.1%
Name:	Microwave And Electric Muffle Furnace	Classification:	Lab Heating Equipments
Highlight:	high temperature muffle furnace , electric muffle furnace

Product Description

Microwave and Electric Muffle Furnace For Sintering

Description

is high temperature muffle furnace with multiple heating source ie. microwave and electric, which can heat materials with higher heating efficiency, faster heating speed and better heating uniformity.

Applications

muffle furnace can be adapted to synthesis, ashing, thermal treatment, roasting, calcination, sintering as well as other chemical process under air atmosphere conditions.

Technical Parameters

Parameters
Power	Voltage	380V±10V 50Hz
	Rated Power	6KW
	Electric Heating Power	3KW
Microwave System	Microwave Output Power	0.10~1.40KW continuously adjustable
	Microwave Frequency	2.45GHz
	Microwave Leakage Prevention	microwave leakage intensity<2mW/cm²
Thermal Insulation System	T_max	1600°C
	Working Temperature	0~1550°C
	Heating Space(L×W×H)	110×110×70mm
Temperature Control System	Temperature Measurement Method	infrared thermometer
	Temperature Measurement Range	300~1800°C
	Temperature Control Precision	±0.1%
Control System	Auto, Manual and Isothermal Controlling Mode, PLC+Touch Screen	40 segments of programmable technical parameters, data storage and export, real-time curve data display, dynamic data display
Safety System	Magnetron Alarm	over temperature alarm
Safety System	Furnace Door Protection Alarm	furnace door shutdown sensor
Overall Dimension	Furnace Body(L×W×H)	ca. 850×650×850mm
Overall Dimension	Floor Area	<1m²
