Commercial Electric Arc Furnace Flexible Smelting Furnace With Water Cooled Roof

Minimum Order Quantity :	Negotiable	Price :	Negotiable
Packaging Details :	Carton, pallet, wooden case or according to customer's package requirements	Delivery Time :	30 working days
Payment Terms :	30% deposit + 70% T/T before shipping	Supply Ability :	20 sets per month

Place of Origin:	CHINA	Brand Name:	OEM
Certification:	CE Certification	Model Number:	OEM

Detail Information
Type 1:	Water Cooled Roof	Type 2:	EAF
Type 3:	LF	Type 4:	Electric Arc Furnace
Type 5:	Ladle Furance	Type 6:	Water Cooled Pipe
Highlight:	eaf electric arc furnace , submerged electric arc furnace

Product Description

Electric Arc Furnace Water Cooled Roof Body Pipe water cooled roof

Mini electric furnace(steel,Iron)

Characteristic:
1. Smelting temperature is flexible to be controlled, meet different steel grade production needs.

2. High heat efficiency, atmosphere inside furnace can be controlled.

3. Can remove the phosphorus, sulfur, oxygen and other impurities and improve steel quality.

4. Easy to control the chemical composition of steel, stable and high recovery rate of alloys.

5. Equipment is simple and shorter technological process.

Rated Capacity	Max. Capacity	Shell Inner Diameter	Electrode Diameter	Transformer Capacity
T	T	MM	MM	KVA
5	10	3200	300	4000
10	18	3600	350	5500
15	24	3800	350	8000
20	30	4000	400	9000
25	35	4200	400	12500
30	45	4400	400	12500-25000
40	55	4600	450	16000-3000
45	65	4800	450	16000-40000
60	85	5400	500	25000-60000
80	100	6100	500	30000-80000
100	120	6400	550	40000-80000

Commercial Electric Arc Furnace Flexible Smelting Furnace With Water Cooled Roof

Tag:

Commercial Electric Arc Furnace Flexible Smelting Furnace With Water Cooled Roof

eaf electric arc furnace

submerged electric arc furnace

Shenzhen LuoX Electric Co., Ltd.
